SPECIFICATIONS
| Specification | MSC-B201 |
| Viewing Head | Compensation free binocular head inclined at 30°IncIined Interpupillary (55-75mm) |
| Eyepiece | Wide Field Eyepiece WF10X18mm ，*WF16×；*WF20×*WF10X22mm |
| Nosepiece | Quadruple Nosepiece |
| Objective | Achromatic Objective 4X,10X,40X,100X |
| Stage | Double Layers Mechanical Stage 140X135mm/ 75X50mm |
| Condense | Abbe NA1.2５ with Iris Diaphragm & Filter |
| Focusing System | Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Coarse Stroke 37.7mm per Rotation, Fine Stroke 0.2mm per Rotation, Moving Range 28mm |
| Illumination | 3W LED Illumination, Brightness Adjustable |
| Halogen Lamp 100V-240V/ 6V20W | |
| Plan-concave Mirror | |
| Package | Carton |
| Filter | White Filter |
| Package Size W*D*H(mm) | 370*260*460 |
| Gross Weight (kg) | 8 |
