Water quality on-line monitoring system.
Simple and quick replacement of filter element
Equipped with portable TDS pen
Double electric water intake,two kinds of water
Suitable for national water quality, the chassis adopts plastic spraying process
The filter element of the system adopts injection molding technology and is built in the chassis
Korean-style fast insert filter column replacement maintenance convenient replacement
Electrical appliances and waterways are completely separated to avoid circuit failures caused by moisture and water leakage.
Water quality on-line monitoring system, which can measure the quality of produced water in real time;
Automatic RO film anti-scale washing procedure, automatic shutdown when the tap water is cut off, automatic shutdown when the tap water is cut off, automatic replenishment of the water storage bucket, automatic shutdown when the water storage bucket is full.
Pipelines are NSF certified, with water quality and quantity upgrade function.
Equipped with portable TDS pen, you can test TDS content, conductivity, water temperature anytime and anywhere.
Double electric water intake, two kinds of water, ready to use.
Front and back door design, simple and quick replacement of filter element, the whole process without using any tools, easy to complete the replacement of filter element.
Application
Application Field
Physicochemical analytical type
All kinds of physical and chemical testing, biochemical analysis, blood examination, microanalysis, flushing special, HPLC, IC, GC, analysis experiment
High sensitivity ICP/MS, PCR, PPT level analysis, isotope analysis, molecular biology, life science, CDC, drug control institute, quality inspection institute, university scientific research and other standard laboratories and a variety of high-end precision instrument water
comprehensive
Molecular biology, Life sciences, gene research, cell culture, amino acid analysis, protein purification, toxicology, drug development, medical testing
Water inlet= water outlet(water outlet≤120LPH,normal 90 LPH)
Case A
Case B
Case C
Water inlet= DI water outlet + UP water outlet
Water inlet= UP water outlet
Water inlet= DI water outlet
Specifications
LWP-S3-2D series
Type
Physicochemical
Low endotoxin
Low TOC
Comprehensive
Model
LWP-S3-2DE
LWP-S3-2DF
LWP-S3-2DV
LWP-S3-2DVF
Water requirements
Pure/distilled water enters the water
DI water indicators
Resistivity
10 to 16 MΩ. cm @ 25℃
Electrical conductivity
< 0.1 us/cm
UP water indicators
Resistivity (25℃)
18.2 MΩ. cm @ 25℃
Heavy metal ion
< 0.01 PPb
Total organic carbon (TOC) *
<10 PPb
<3 PPb
Bacteria
< 0.01 cfu/ml
Pyrogen (endotoxin)
N/A
< 0.001 Eu/ml
N/A
< 0.001 Eu/ml
Particulate matter (> 0.1 microns)
<1/ml
Ribonuclease (RNases)
N/A
<1pg/ml
N/A
<1pg/ml
Deoxyribonucleases
N/A
<5pg/ml
N/A
<5pg/ml
Dimensions (L×W×H)
41*27*50cm
Weight
30Kg
31Kg
31Kg
32Kg
Electricity
100-240V, 50/60Hz, 48-72W
System configuration
Host (including 1 set of purification column)+TDS pen + accessory bag
