| Model | WS-041 | WS-042 |
| Machine Capacity (mm) | 25 mm | 25 mm |
| Column Dia. (mm) | 92 mm | 92 mm |
| Center of Spindle to column (mm) | 250 mm | 250 mm |
| Distance Spindle to Table (mm) | 645 mm | 660 mm |
| Distance Spindle to Base (mm) | 1000 mm | 1045 mm |
| Distance from Spindle Centre to (mm) | 250 max | 250 max |
| Pillar Surface | ||
| Table Travel | 480 mm | 480 mm |
| Spindle Nose | MT-3 | MT-3 |
| Spindle Travel (mm) | 250 mm | 180 mm |
| Range of Spindle speed (RPM) | 70-2000 | 130-2600 |
| No. of Spindle Speed | 8 | 8 |
| Table Size (mm) | 330 x 330 mm | 330 x 330 mm |
| Base Sie (Machined Area) (mm) | 255 x 310 mm | 365 x 575 mm |
| Overall Height with guard (mm) | 1780 mm | 1730 mm |
| Main Electrical Motor | 1 H. P. | 1 H. P. |
