Laminar Flow Hood / Laminar Flow Cabinet /  Clean Bench, Horizontal type

We offer a variety of laminar flow hood (clean bench) designed for a variety of research and engineering needs. The selection includes horizontal, vertical and bench-top laminar flow workstations. They can provide efficient protection for your samples, HEPA Filter Efficiency is more than 99.995% at particle size at 0.3 μm

LCB-HF Series Horizontal Laminar Flow Hood provides a sterile work zone through a purified air that travels in a horizontal, unidirectional stream and leaves the main work chamber across the entire open front of the cabinet.

Applications

• Plant tissue culture
• Media plate preparation
• Electronics inspection
• Medical device assembly

Advantages

Humanized Features

• Ergonomic Control Panel Location, centered and angled down for an easy reach & viewing.
• Brushed stainless steel work surface is for easy cleaning
• The non-direct light source design can effectively relieve the operator’s visual fatigue under the condition of ensuring the illumination
• Intuitive and easy-to-use microprocessor controller with LCD display, graphical and digital display of the operating status of each function, such as filter life, UV life etc.

 Safety Features

• Front sliding sash interlock with fan and UV lamp
• UV sterilization with UV lamp timing function
• Front sash and side windows are made of UV-resistant tempered glass
• The host and sockets have independent capacitors to prevent current overload

Convenience Features

• Memory function in case of power-failure.
• HEPA filter and UV life indicators facilitate a timely replacement plan
• Two side glass windows installed for easy experiment observation
• Easy-to-change pre-filter installed could extend the HEPA filter’s lifetime
• Equipped with temperature sensor to show the real temperature during operation
• Waterproof socket provide convenience for small instruments to be used in the operating area
